Wildly popular Hilux Vigo's proud predecessor is Hilux Tiger. Please note that we are using the Toyota Tiger as a category to include Toyota D4D Tiger which was officially called Sportcruiser but is still called Toyota Tiger by some dealers. Toyota had been building cars and trucks in Thailand since 1956 and now owns three major assembly plants here, with vehicles and parts being exported to other countries.  It was with the Hilux Tiger, that Toyota decided to make Thailand the hub of its manufacturing: instead of exporting Hilux from its Japanese plant, it made a strategic shift by exporting it to Australia from its Thai plant. Vigo is now being exported worldwide.

The Hilux Tiger was nearly identical to most other Hiluxes of its generation, with the exception that it uses the newer D4D engine, not found in Australia, New Zealand and South African markets.  In addition, Toyota manufactured several unique models in Thailand, including the Sport-Rider, among others. Sports Rider was a SUV built on Hilux platform.

Pre-owned Hilux Tiger Double Cab and Extra Cab 1998-2004 available now in 5L, 5L EFI, 1KZ, D4D engines

Toyota Hilux Tiger has the following generations:

Pre-owned Hilux Double Cabs and Extra cab are currently in stock from 2000 till 2004 but we also acquire models of earlier years upon request. The 2001 model is TOYOTA 3.0 L EFI Engine, 4 doors, 4x4 Manual Transmission, and standard options are, Driver-side airbag, ABS Brakes, Power Steering, Power Windows, Electric Side Mirrors, Cassette Player/Radio AM FM, Fabric Seatings and A/C.  Since Thailand is warm 12 months a year, none of these cars have any heaters but we can install high quality heaters for all kinds of weather. For some Images (Pics) of Toyota Hilux Tiger model 2000 and 2001 we have exported please check our page on Toyota Hilux Tiger 2000 and 2001 model with EFI engine. Toyota introduced Toyota Hilux Tiger in 1KZ engine in 2001 but later that year it introduced Tiger in its most successful engine D4D, see some Images (Pics) of Toyota Hilux Tiger D4D on our Toyota Hilux Tiger D4D page.

5L-E Engine

The 5L-E is a 3.0 L (2986 cc) EFI version of the 5L engine. It is the latest member of the L family. It has a bore of 99.5 mm and stroke of 96 mm, with a compression ratio of 22.2:1. Output is 96.5 hp (72 kW) at 4000 RPM with 141.6 ft·lb (192 N·m) of torque at 2400 RPM.

Model Type Cam Dimension Capacity HP Torque Drive Comment
5L 4 OHC DiV. 99.5x96 2986 CC. 97/4000 192nm/2400 FR Tiger

The L family first appeared in October 1977, it is a series of 4 cylinder diesel engines. It is the first diesel engine from Toyota to use a rubber timing belt in conjunction with a SOHC head.

EFI stands for Electronic Fuel Injection. Fuel injection atomizes the fuel by forcibly pumping it through a small nozzle under high pressure. The fuel injector is only a nozzle and a valve: the power to inject the fuel comes from farther back in the fuel supply, from a pump or a pressure container.

1 KZ engine

In 2001 Toyota finally decided to give the old 5L workhorse rest and first came with tested and tried 1KZ engine of Toyota Prado and then changed its mind and put D4D engine in the entire Toyota Hilux family: Toyota Hilux Tiger, Toyota Hilux Sport Cruiser and its SUV Toyota Hilux Sport Rider.

Model Type Cam Dimension Capacity HP Torque
1KZ TE 4 OHV 8 V. 96x103 2982 CC. 125/3600 32.1/2000



D4D Engine



Toyota Hilux Tiger 1998 - 2004 Specifications

Toyota Hilux Tiger 1998 Models

Toyota Hilux Tiger July 1998 Models

Toyota Hilux Tiger 1999 models

Toyota Hilux Tiger September 1999

Toyota Hilux Tiger early 2000

Toyota Hilux Tiger July 2000

Toyota Hilux Tiger 2001

Toyota Hilux Tiger 2002

Toyota Hilux Tiger 2003

Toyota Hilux Tiger 2004

Toyota Hilux Tiger Specs

Toyota Hilux Tiger 1998 specs

1998 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp 4WD 3.0D LN167R-CRMSST(01)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN167R-CRMSST(01)
VIN MR032LNF50-7###
Drive 4 wheel drive
Transmission 5sp Manual
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Ext. Cab SR5 Man 5sp 4WD 3.0D LN167R-CRMSSTA(01)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SR5
Doors 2
Seat Capacity 2
Model Code LN167R-CRMSSTA(01)
VIN MR032LNG90-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Single Cab Economy Man 5sp RWD 2.4D (LWB) LN155R-TRMDST(00)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Single Cab
Badge Economy
Doors 2
Seat Capacity 2
Model Code LN155R-TRMDST(00)
VIN MR031LNF-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 2.4D (WS,SWB) LN145R-TRMDST(04)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN145R-TRMDST(04)
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 2.4D (LWB) LN155R-TRMDSTA(00)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN155R-TRMDSTA(00)
VIN MR031LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 2.4D (PS,SWB) LN145R-TRMDST(00)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN145R-TRMDST(00)
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 3.0D (PS,LWB) LN157R-TRMDST(00)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN157R-TRMDST(00)
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp RWD 1170kg 2.4D LN150R-CRMSST(00)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN150R-CRMSST(00)
VIN MR032LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 76HP
Kerb Weight 1410kg
Gross Vehicle Mass 2580kg
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp RWD 1170kg 2.4D (PS) LN150R-CRMSSTA(00)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN150R-CRMSSTA(00)
VIN MR032LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 76HP
Kerb Weight 1410kg
Gross Vehicle Mass 2580kg
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp RWD 3.0D (PS) LN152R-CRMSSTA(00)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN152R-CRMSSTA(00)
VIN MR031LNF-9###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Man 5sp RWD 3.0D (MP) LN152R-CRMSSTB(01)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
Model Code LN152R-CRMSSTB(01)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Auto 4sp RWD 3.0D (MP) LN152R-CRPSST(01)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
Model Code LN152R-CRPSST(01)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 4sp Automatic
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Prerunner Man 5sp RWD 3.0D (MP) LN192R-CRMSST(01)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL Prerunner
Doors 2
Seat Capacity 2
Model Code LN192R-CRMSST(01)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1998 Toyota Hilux Tiger pickup4dr DCab Man 5sp RWD 2.4D LN145R-TRMDST(04)

Release Date 1998
Body Style PICKUP TRUCK
Body Config Dual Cab
Doors 4
Seat Capacity 5
Model Code LN145R-TRMDST(04)
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger New Models

1999 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp RWD 1170kg 2.4D (PS,VVS) LN150R

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN150R
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 113HP
Torque 156Nm @ 2400RPM
Kerb Weight 1410kg
Gross Vehicle Mass 2580kg
Wheelbase 3085mm
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp RWD 1170kg 2.4D (VVS)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 113HP
Torque 156Nm @ 2400RPM
Kerb Weight 1410kg
Gross Vehicle Mass 2580kg
Wheelbase 3085mm
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Man 5sp RWD 1170kg 3.0D (MP,VVS)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Kerb Weight 1410kg
Gross Vehicle Mass 2580kg
Wheelbase 3085mm
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Auto 4sp RWD 1155kg 3.0D (MP,VVS)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 4sp Automatic
Gear Location Floor
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Mechanical
Induction Aspirated
Power 88HP
Kerb Weight 1425kg
Gross Vehicle Mass 2580kg
Wheelbase 3085mm
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab SR5 Man 5sp 4WD 3.0D LN167R-CRMSSTA(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SR5
Doors 2
Seat Capacity 2
Model Code LN167R-CRMSSTA(10)
VIN MR032LNG90-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



September 1999 Models Specs

1999 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 2.4D (PS,SWB) LN145R-TRMDST(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN145R-TRMDST(10)
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 2.4D (LWB) LN155R-TRMDSTA(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Model Code LN155R-TRMDSTA(10)
VIN MR031LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Single Cab Economy Man 5sp RWD 2.4D (LWB) LN155R-TRMDST(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Single Cab
Badge Economy
Doors 2
Seat Capacity 2
Model Code LN155R-TRMDST(10)
VIN MR031LNF-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 3.0D (PS,LWB) LN157R-TRMDST(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN157R-TRMDST(10)
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp RWD 1170kg 2.4D LN150R-CRMSST(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN150R-CRMSST(10)
VIN MR032LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 76HP
Kerb Weight 1410kg
Gross Vehicle Mass 2580kg
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp RWD 1170kg 2.4D (PS) LN150R-CRMSSTA(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN150R-CRMSSTA(10)
VIN MR032LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 76HP
Kerb Weight 1410kg
Gross Vehicle Mass 2580kg
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Man 5sp RWD 2.4D (PS) LN150R-CRMSSTB(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
Model Code LN150R-CRMSSTB(10)
VIN MR032LNF70-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Man 5sp RWD 3.0D (MP) LN152R-CRMSST(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
Model Code LN152R-CRMSST(10)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Auto 4sp RWD 3.0D (MP) LN152R-CRPSST(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
Model Code LN152R-CRPSST(10)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 4sp Automatic
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Prerunner Man 5sp RWD 3.0D (MP) LN192R-CRMSST(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL Prerunner
Doors 2
Seat Capacity 2
Model Code LN192R-CRMSST(10)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



1999 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp 4WD 3.0D LN167R-CRMSST(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN167R-CRMSST(10)
VIN MR032LNF50-7###
Drive 4 wheel drive
Transmission 5sp Manual
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



Toyota Hilux Tiger 2000 Specs

2000 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 2.4D (LWB) LN155R-TRMDSTA(20)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN155R-TRMDSTA(20)
VIN MR031LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Single Cab GL Man 5sp RWD 3.0D (PS,LWB) LN157R-TRMDET(00)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN157R-TRMDET(00)
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 95HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Man 5sp RWD 2.4D (MP,PS) LN150R-CRMSSTB(10)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
Model Code LN150R-CRMSSTB(10)
VIN MR032LNF70-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp RWD 1170kg 2.4D (PS) LN150R-CRMSSTA(20)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN150R-CRMSSTA(20)
VIN MR032LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Kerb Weight 1410kg
Gross Vehicle Mass 2580kg
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Man 5sp RWD 3.0D (MP) LN152R-CRMSET(00)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
Model Code LN152R-CRMSET(00)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 95HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Prerunner Man 5sp RWD 3.0D (MP) LN192R-CRMSET(00)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL Prerunner
Doors 2
Seat Capacity 2
Model Code LN192R-CRMSET(00)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 95HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Auto 4sp RWD 3.0D (MP) LN152R-CRPSET(00)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
Model Code LN152R-CRPSET(00)
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 4sp Automatic
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 95HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab GL Man 5sp 4WD 3.0D (MP) LN167R-CRMSET(00)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge GL
Doors 2
Seat Capacity 2
Model Code LN167R-CRMSET(00)
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 95HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab SR5 Man 5sp 4WD 3.0D (MP) LN167R-CRMSETA(00)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SR5
Doors 2
Seat Capacity 2
Model Code LN167R-CRMSETA(00)
VIN MR032LNG90-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 95HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab SR5 Man 5sp 4WD 3.0DT (MP) KZN165R-CRMSTT(00)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SR5
Doors 2
Seat Capacity 2
Model Code KZN165R-CRMSTT(00)
VIN MR032LNG90-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Engine Code IKZ-TE
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Electronic
Induction Turbo
Power 113HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup4dr DCab GL Man 5sp RWD 2.4D LN145R-PRMDST(20)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Dual Cab
Badge GL
Doors 4
Seat Capacity 5
Model Code LN145R-PRMDST(20)
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup4dr DCab GL Man 5sp 4WD 3.0D LN167R-PRMSET(00)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Dual Cab
Badge GL
Doors 4
Seat Capacity 5
Model Code LN167R-PRMSET(00)
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup4dr DCab GL Man 5sp 4WD 3.0D LN167R-PRMSET(01)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Dual Cab
Badge GL
Doors 4
Seat Capacity 5
Model Code LN167R-PRMSET(01)
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



July 2000 additions

2000 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Man 5sp RWD 2.4D (MP,VVS)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL
Doors 2
Seat Capacity 2
VIN MR032LNF70-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 76HP
Wheelbase 3085mm
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab SGL Prerunner Man 5sp RWD 3.0D (MP,VVS)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SGL Prerunner
Doors 2
Seat Capacity 2
VIN MR032LNG90-7###
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



2000 Toyota Hilux Tiger pickup2dr Ext. Cab SR5 Man 5sp 4WD 3.0D (MP,VVS)

Release Date 2000
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SR5
Doors 2
Seat Capacity 2
VIN MR032LNG90-7###
Drive 4 wheel drive
Transmission 5sp Manual
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Aspirated
Power 88HP



2001 Model

2001 Toyota Hilux Tiger pickup2dr Single Cab Standard Man 5sp RWD 2.4D (PS,MP) LN155R-TRMDST/30

Standard Equipment Aerial, Air-conditioning, Ashtray, front, Bumpers, black, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Door handles, black, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Mirrors, side - black, Passenger assist grips, Seat trim, vinyl, Steering, tilt/rake adjustable, Warning lamp - door ajar, Warning lamp - low fuel, Wheels, steel
Release Date 2001
Body Style PICKUP TRUCK
Body Config Single Cab
Badge Standard
Doors 2
Seat Capacity 2
Model Code LN155R-TRMDST/30
VIN MR031LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Engine Code 2L
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 73HP
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Single Cab J Standard Man 5sp RWD 2.5DT KDN155R-TRMDYT10

Standard Equipment Aerial, Air-conditioning, Ashtray, front, Audio - cassette player, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Door handles, black, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Mirrors, side - black, Passenger assist grips, Power steering, Seat trim, vinyl, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Wheel trims, Wheels, steel
Release Date 2001
Body Style PICKUP TRUCK
Body Config Single Cab
Badge J Standard
Doors 2
Seat Capacity 2
Model Code KDN155R-TRMDYT10
VIN MR031LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2494cc (2.5)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 4
Compression Ratio 18.5:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 2KD-FTV
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 100HP
Torque 200Nm @ 1400RPM
Kerb Weight 1390kg
Wheelbase 2960mm
Length 4900mm
Width 1700mm
Height 1605mm
Track Front 1400mm
Track Rear 1410mm
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Single Cab GL Sport Edition Man 5sp RWD 3.0DT (MP) LN152R-CRMSET(01)

Standard Equipment Aerial, Air-conditioning, Ashtray, front, Audio - cassette player, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Door handles, black, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Mirrors, side - black, Passenger assist grips, Power steering, Seat trim, vinyl, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Wheel trims, Wheels, steel
Release Date 2001
Body Style PICKUP TRUCK
Body Config Single Cab
Badge GL Sport Edition
Doors 2
Seat Capacity 2
Model Code LN152R-CRMSET(01)
VIN MR031LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 95HP
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab Man 5sp RWD 2.4D (PS,MP) LN150R-CRMDST11

Standard Equipment Aerial, Air-conditioning, Ashtray, front, Audio - cassette player, Bumpers, black, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Door handles, black, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Mirrors, side - black, Passenger assist grips, Seat trim, vinyl, Steering, tilt/rake adjustable, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, steel
Release Date 2001
Body Style PICKUP TRUCK
Body Config Extended Cab
Doors 2
Seat Capacity 2
Model Code LN150R-CRMDST11
VIN MR031LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Compression Ratio 23.5:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 2L
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 73HP
Torque 157Nm @ 2400RPM
Kerb Weight 1435kg
Length 5035mm
Width 1700mm
Height 1610mm
Track Front 1400mm
Track Rear 1410mm
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab J Man 5sp RWD 2.5DT KDN150R-CRMSYTB10

Standard Equipment Aerial, Air-conditioning, Ashtray, front, Audio - cassette player, Bumpers, body coloured, Center armrest, front, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Door handles, black, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Mirrors, side - black, Passenger assist grips, Power steering, Seat trim, fabric, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheel trims, Wheels, steel
Release Date 2001
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge J
Doors 2
Seat Capacity 2
Model Code KDN150R-CRMSYTB10
VIN MR032LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2494cc (2.5)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 4
Compression Ratio 18.5:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 2KD-FTV
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 100HP
Torque 200Nm @ 1400RPM
Kerb Weight 1450kg
Wheelbase 3085mm
Length 5035mm
Width 1700mm
Height 1625mm
Track Front 1400mm
Track Rear 1410mm
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab E Man 5sp RWD 2.5DT (ABS,AB,MP) KDN150R-CRMSYT12

Standard Equipment Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers, body coloured, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Driver's footrest, Fog lights, Front, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, High-mount rear sbest lamp, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Passenger assist grips, Power steering, Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2001
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge E
Doors 2
Seat Capacity 2
Model Code KDN150R-CRMSYT12
VIN MR032JNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2494cc (2.5)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 4
Compression Ratio 18.5:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 2KD-FTV
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 100HP
Torque 200Nm @ 1400RPM
Kerb Weight 1450kg
Wheelbase 3085mm
Length 5035mm
Width 1700mm
Height 1625mm
Track Front 1425mm
Track Rear 1435mm
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab E Man 5sp RWD 2.5DT (MP) KDN150R-CRMSYTA12

Standard Equipment Aerial, electric, Air-conditioning, Ashtray, front, Audio - cassette player, Bumpers, body coloured, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Door handles, chrome, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, High-mount rear sbest lamp, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Passenger assist grips, Power steering, Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2001
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge E
Doors 2
Seat Capacity 2
Model Code KDN150R-CRMSYTA12
VIN MR032JNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2494cc (2.5)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 4
Compression Ratio 18.5:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 2KD-FTV
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 100HP
Torque 200Nm @ 1400RPM
Kerb Weight 1450kg
Wheelbase 3085mm
Length 5035mm
Width 1700mm
Height 1625mm
Track Front 1425mm
Track Rear 1410mm
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab E Prerunner Auto 4sp RWD 2.5DT KDN190R-CRPSYT10

Standard Equipment Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers, body coloured, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, High-mount rear sbest lamp, Indicator, Gear Selection, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Panelling, wood (&imitation), Passenger assist grips, Power steering, Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2001
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge E Prerunner
Doors 2
Seat Capacity 2
Model Code KDN190R-CRPSYT10
VIN MR032JNF50-7###
Drive Rear wheel drive
Transmission 4sp Automatic
Gear Location Floor
Steering Recirculating Ball
Engine Size 2494cc (2.5)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 4
Compression Ratio 18.5:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 2KD-FTV
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 100HP
Torque 260Nm @ 1600RPM
Kerb Weight 1600kg
Wheelbase 2860mm
Length 4920mm
Width 1790mm
Height 1795mm
Track Front 1485mm
Track Rear 1470mm
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab S Man 5sp 4WD 2.5DT KDN165R-CRMSYT10

Standard Equipment Air-conditioning, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers - chrome, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Hi-Lo Ratio Gear Transfer, High-mount rear sbest lamp, Indicator, 4WD Mode, Limited Slip Differential, Rear, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Passenger assist grips, Power steering, Remote Free Hub (2/4WD mode), Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2001
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge S
Doors 2
Seat Capacity 2
Model Code KDN165R-CRMSYT10
VIN MR031LNF50-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2494cc (2.5)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 4
Compression Ratio 18.5:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 2KD-FTV
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 100HP
Torque 260Nm @ 1600RPM
Kerb Weight 1580kg
Length 4920mm
Width 1790mm
Height 1795mm
Track Front 1485mm
Track Rear 1470mm
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab G Man 5sp RWD 3.0DT (MP)

Release Date 2001
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G
Doors 2
VIN MR032GNG50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Turbo
Power 113.9HP
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab SR5 Man 5sp 4WD 3.0D LN167R-CRMSSTA(10)

Release Date 1999
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SR5
Doors 2
Seat Capacity 2
Model Code LN167R-CRMSSTA(10)
VIN MR032LNG90-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 88HP
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup2dr Ext. Cab SR5 Sport Edition Man 5sp 4WD 3.0DT (MP) LN167R-CRMSETA(01)

Release Date 2001
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge SR5 Sport Edition
Doors 2
Seat Capacity 2
Model Code LN167R-CRMSETA(01)
VIN MR032LNG90-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 95HP
Country Of Origin THAILAND



2001 Toyota Hilux Tiger pickup4dr DCab Super GL Man 5sp RWD 2.4D LN145R-TRMDST(21)

Release Date 2001
Body Style PICKUP TRUCK
Body Config Dual Cab
Badge Super GL
Doors 4
Seat Capacity 5
Model Code LN145R-TRMDST(21)
Drive Rear wheel drive
Transmission 5sp Manual
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 76HP
Country Of Origin THAILAND



2002 Toyota Hilux Tiger

2002 Toyota Hilux Tiger pickup2dr Ext. Cab G Man 5sp RWD 3.0DT (ABS,SRS,MP) KDN151R-CRMSYT02

Standard Equipment Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers - chrome, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, High-mount rear sbest lamp, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Passenger assist grips, Power steering, Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2002
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G
Doors 2
Seat Capacity 2
Model Code KDN151R-CRMSYT02
VIN MR032GNG50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 123HP
Torque 315Nm @ 1800RPM
Kerb Weight 1490kg
Wheelbase 3085mm
Length 5035mm
Width 1700mm
Height 1625mm
Track Front 1425mm
Track Rear 1435mm
Country Of Origin THAILAND



2002 Toyota Hilux Tiger pickup2dr Ext. Cab G Limited Man 5sp 4WD 3.0DT (2TP) KDN166R-CRMSYTA00

Standard Equipment 2-tone paint, Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers - chrome, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Driver's footrest, Fog lights, Front, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Hi-Lo Ratio Gear Transfer, High-mount rear sbest lamp, Indicator, 4WD Mode, Limited Slip Differential, Rear, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Panelling, wood (&imitation), Passenger assist grips, Power steering, Remote Free Hub (2/4WD mode), Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Seat trim, leather, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2002
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G Limited
Doors 2
Seat Capacity 2
Model Code KDN166R-CRMSYTA00
VIN MR032GNG50-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 123HP
Torque 315Nm @ 1800RPM
Acceleration 0-100Km/h 14.59 secs
Kerb Weight 1586kg
Wheelbase 3085mm
Length 4920mm
Width 1790mm
Height 1795mm
Track Front 1485mm
Track Rear 1470mm
Country Of Origin THAILAND



2002 Toyota Hilux Tiger pickup2dr Ext. Cab G Limited Auto 4sp 4WD 3.0DT (2TP) KDN166R-CRPSYTA00

Standard Equipment 2-tone paint, Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers - chrome, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Driver's footrest, Fog lights, Front, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Hi-Lo Ratio Gear Transfer, High-mount rear sbest lamp, Indicator, 4WD Mode, Indicator, Gear Selection, Limited Slip Differential, Rear, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Panelling, wood (&imitation), Passenger assist grips, Power steering, Remote Free Hub (2/4WD mode), Seat Belt Pretensioners-Front Seats, Seat trim, leather, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Optional Equipment 2-tone paint
Release Date 2002
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G Limited
Doors 2
Seat Capacity 2
Model Code KDN166R-CRPSYTA00
VIN MR032GNG50-7###
Drive 4 wheel drive
Transmission 4sp Automatic
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 123HP
Torque 315Nm @ 1800RPM
Acceleration 0-100Km/h 17.12 secs
Kerb Weight 1597kg
Wheelbase 3085mm
Length 4920mm
Width 1790mm
Height 1795mm
Track Front 1485mm
Track Rear 1470mm
Country Of Origin THAILAND



2002 Toyota Hilux Tiger pickup2dr Ext. Cab G Man 5sp 4WD 3.0DT KDN166A/00

Standard Equipment Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers - chrome, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Hi-Lo Ratio Gear Transfer, High-mount rear sbest lamp, Indicator, 4WD Mode, Limited Slip Differential, Rear, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Passenger assist grips, Power steering, Remote Free Hub (2/4WD mode), Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Optional Equipment 2-tone paint
Release Date 2002
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G
Doors 2
Seat Capacity 2
Model Code KDN166A/00
VIN MR032GNG50-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 123HP
Torque 315Nm @ 1800RPM
Acceleration 0-100Km/h 14.59 secs
Kerb Weight 1586kg
Wheelbase 3085mm
Length 4920mm
Width 1790mm
Height 1795mm
Track Front 1485mm
Track Rear 1470mm
Country Of Origin THAILAND



2002 Toyota Hilux Tiger pickup2dr Ext. Cab G Auto 4sp 4WD 3.0DT KDN166R-CRPSYT00

Standard Equipment Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers - chrome, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Hi-Lo Ratio Gear Transfer, High-mount rear sbest lamp, Indicator, 4WD Mode, Indicator, Gear Selection, Limited Slip Differential, Rear, Map lights, Front, Metallic paint, Mirrors, side - chrome, Mirrors, side - electric, Passenger assist grips, Power steering, Remote Free Hub (2/4WD mode), Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2002
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G
Doors 2
Seat Capacity 2
Model Code KDN166R-CRPSYT00
VIN MR032GNG50-7###
Drive 4 wheel drive
Transmission 4sp Automatic
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 123HP
Torque 315Nm @ 1800RPM
Acceleration 0-100Km/h 17 secs
Kerb Weight 1597kg
Wheelbase 3085mm
Length 4920mm
Width 1790mm
Height 1795mm
Track Front 1485mm
Track Rear 1470mm
Country Of Origin THAILAND



Toyota Hilux Tiger 2003 Models

2003 Toyota Hilux Tiger pickup2dr Single Cab Standard Man 5sp RWD 2.4D LN155R-TRMDST40

Standard Equipment Aerial, Air-conditioning, Ashtray, front, Bumpers, black, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Door handles, black, Driver's footrest, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Mirrors, side - black, Passenger assist grips, Seat trim, vinyl, Steering, tilt/rake adjustable, Warning lamp - door ajar, Warning lamp - low fuel, Wheels, steel
Optional Equipment Metallic paint, Power steering
Release Date 2003
Body Style PICKUP TRUCK
Body Config Single Cab
Badge Standard
Doors 2
Seat Capacity 2
Model Code LN155R-TRMDST40
VIN MR031LNF50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2446cc (2.4)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 2
Compression Ratio 23.5:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 2L
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Single-Point Injected
Method Of Delivery Mechanical
Induction Aspirated
Power 73HP
Torque 157Nm @ 2400RPM
Kerb Weight 1370kg
Wheelbase 2960mm
Length 4900mm
Width 1700mm
Height 1605mm
Track Front 1400mm
Track Rear 1410mm
Country Of Origin THAILAND



2003 Toyota Hilux Tiger pickup2dr Ext. Cab G Man 5sp RWD 3.0DT (BLKT) KDN166A/00

Standard Equipment Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - cassette player, Brake, Anti-Lock (ABS), Bumpers - chrome, Center armrest, front, Central locking, Centre console with storage box/lid, Centre console, overhead, Cigarette lighter, front, Clock, digital, Cup holders, front, Demister, rear window, Door handles, chrome, Door sill scuff plate, Driver's footrest, Fog lights, Front, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, High-mount rear sbest lamp, Map lights, Front, Metallic paint, Mirrors, side - body coloured, Mirrors, side - electric, Panelling, aluminum (&imitation), Passenger assist grips, Power steering, Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Seat trim, leather, Spoiler/skirt, side, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2003
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G
Doors 2
Seat Capacity 2
Model Code KDN166A/00
VIN MR032GNG50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 123HP
Torque 315Nm @ 1800RPM
Kerb Weight 1490kg
Wheelbase 3085mm
Length 5035mm
Width 1700mm
Height 1625mm
Track Front 1425mm
Track Rear 1435mm
Country Of Origin THAILAND



2003 Toyota Hilux Tiger pickup2dr Ext. Cab G Limited Man 5sp 4WD 3.0DT (BLKT) KDN166R-CRMSYTA00

Standard Equipment 2-tone paint, Aerial, electric, Air-conditioning, Airbag, driver's, Ashtray, front, Audio - 1-CD player, Brake, Anti-Lock (ABS), Bumpers - chrome, Center armrest, front, Central locking, Centre console with storage box/lid, Cigarette lighter, front, Clock, digital, Cup holders, front, Cup holders, Rear, Demister, rear window, Door handles, chrome, Door sill scuff plate, Driver's footrest, Fog lights, Front, Gauge, Coolant Temperature, Gauge, fuel, Glovebox, Headrests, Height Adjustable Front, Hi-Lo Ratio Gear Transfer, High-mount rear sbest lamp, Indicator, 4WD Mode, Limited Slip Differential, Rear, Map lights, Front, Metallic paint, Mirrors, front convex/parking, Mirrors, side - chrome, Mirrors, side - electric, Panelling, wood (&imitation), Passenger assist grips, Power steering, Remote Free Hub (2/4WD mode), Seat Belt Pretensioners-Front Seats, Seat trim, fabric, Seat trim, leather, Steering, tilt/rake adjustable, Sunvisors w/ Vanity Mirrors, Tachometer, Tripmeter, Warning lamp - door ajar, Warning lamp - low fuel, Warning lamp - seat belt on, Wheels, alloy, Windows, electric - front only
Release Date 2003
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G Limited
Doors 2
Seat Capacity 2
Model Code KDN166R-CRMSYTA00
VIN MR032GNG50-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 4
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 123HP
Torque 315Nm @ 1800RPM
Acceleration 0-100Km/h 14.59 secs
Kerb Weight 1586kg
Wheelbase 3085mm
Length 4920mm
Width 1790mm
Height 1795mm
Track Front 1485mm
Track Rear 1470mm
Country Of Origin THAILAND



Toyota Hilux Tiger 2004

2004 Toyota Hilux Tiger pickup2dr Ext. Cab G Limited Man 5sp RWD 3.0DTi (ABS,SRS,MP) KDN151R-CRMSYT02

Release Date 2003
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G Limited
Doors 2
Seat Capacity 2
Model Code KDN151R-CRMSYT02
VIN MR032GNG50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo intercooled
Power 123HP
Torque 315Nm @ 1800RPM
Kerb Weight 1490kg
Wheelbase 3085mm
Length 5035mm
Width 1700mm
Height 1625mm
Track Front 1425mm
Track Rear 1435mm
Country Of Origin THAILAND



2004 Toyota Hilux Tiger pickup2dr Ext. Cab G Limited Man 5sp RWD 3.0DTi (ABS,SRS,YRM) KDN151R-CRMSYT02

Release Date 2004
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G Limited
Doors 2
Seat Capacity 2
Model Code KDN151R-CRMSYT02
VIN MR032GNG50-7###
Drive Rear wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 69L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo intercooled
Power 123HP
Torque 315Nm @ 1800RPM
Kerb Weight 1490kg
Wheelbase 3085mm
Length 5035mm
Width 1700mm
Height 1625mm
Track Front 1425mm
Track Rear 1435mm
Country Of Origin THAILAND



2004 Toyota Hilux Tiger pickup2dr Ext. Cab G Limited Man 5sp 4WD 3.0DT (YRM) KDN166R-CRMSYTA00

Release Date 2002
Body Style PICKUP TRUCK
Body Config Extended Cab
Badge G Limited
Doors 2
Seat Capacity 2
Model Code KDN166R-CRMSYTA00
VIN MR032GNG50-7###
Drive 4 wheel drive
Transmission 5sp Manual
Gear Location Floor
Steering Recirculating Ball
Engine Size 2982cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Double Overhead Cam
Valves Per Cylinder 2
Compression Ratio 18.4:1
Engine Cycle 4 Stroke
Engine Type Piston
Engine Location Front
Engine Code 1KD-FTV
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Direct Injection
Method Of Delivery Electronic
Induction Turbo
Power 123HP
Torque 315Nm @ 1800RPM
Acceleration 0-100Km/h 14.59 secs
Kerb Weight 1586kg
Wheelbase 3085mm
Length 4920mm
Width 1790mm
Height 1795mm
Track Front 1485mm
Track Rear 1470mm
Country Of Origin THAILAND



Toyota Hilux Tiger 2002 Specs

    mm mm mm mm kg ps
SERIES MODEL

L

W

H

W.B

Weight

 HP(NET)
HILUX TIGER Extra Cab C-CAB(4x2) 3.0SGLauto 4975 1690 1625 3085 1426 97/4000
3.0SGL 1625 1410 97/4000
3.0GL 1610 1410 97/4000
2.4GL 1610 1410 85/4200
HILUX TIGER Single Cab B-CAB(4x2) 3.0GL 4840 1690 1605 2690 1370 97/4000
2.4GL 4840 1690 1370 85/4200
2.4Economy 4840 1690 1370 85/4200
2.4GL 4730 1690 1335 85/4200
HILUX TIGER SportPickUp PRERUNNER(4x2) 4860 1690 1795 2660 1490 97/4000
GL(4x4) 1600 97/4000
SR5(4x4) 1600 97/4000
SPORTS RIDER PRERUNNER(4x2) 4590   1775 2860 1730 97/4000
SR5(4x4) 4590 1775 1775 1840
SR5LTD(4x4) 4985 1775 1795 1875
SERIES MODEL P/S P/W ABS Air
Bag

Ra-
dio

Auto Mirror

Center
Lock

 DEF GOA T.R.

F.T.
ltrs
HILUX TIGER ExtraCab C-CAB(4x2) 3.0SGLauto O O O   O O O   O 5.9 69
3.0SGL O O O   O O O   O
3.0GL O       O       O
2.4GL X       O       O
HILUX TIGER SingleCab B-CAB(4x2) 3.0GL O       O       O 5.8 69
2.4GL         O       O 6
2.4Economy         O       O 6
2.4GL O       O       O 5.7
HILUX TIGER SportPickUp PRERUNNER(4x2) O O O O O O O   O 6.1 71
GL(4x4) O       O       O
SR5(4x4) O O O O O O O   O
SPORTS RIDER PRERUNNER(4x2) O O O O O O O O O 6.6 71

Legends: L-length W-width H-height W.B.-Wheelbase HP: Horsepower P/S: Power steering P/W: Power windows T.R: Turning Radius F.T.: Fuel Tank

Double Cab (Crew Cab) Tiger Prerunner 1998 LN167R-CRMSST

Toyota Hilux Crew Cab Pick Up, 4WD Drive

Model: LN167R-CRMSST

Engine: 5L Diesel 4 Cylinder in Line OHC 8 Valve Piston Displacement 2986cc Max. horsepower 66Kw/4000rpm

Transmission: 5 Speed Manual Transmission, Floor Shift, All Forward gears synchromesh with 1 reverse.

Tyre Size: Fr. & Rr. 255/70 R15

Release Date 1998
Body Style WAGON
Badge Prerunner
Doors 4
Seat Capacity 5
Model Code LN192R-CRMSST(04)
VIN MR032LNK90-7###
Drive Rear wheel drive
Transmission 5sp Manual, Floor Shift, All Forward gears synchromesh with 1 reverse.
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Kerb Weight 1730kg
Gross Vehicle Mass 2590kg
Wheelbase 2860mm
Country Of Origin THAILAND





Toyota Hilux Tiger 1999 model Sport Rider Wagon 4dr SR5 Man 5sp 4WD 3.0D LN167R-CRMSST(04)

Release Date 1998
Body Style WAGON
Badge SR5
Doors 4
Seat Capacity 5
Model Code LN167R-CRMSST(04)
VIN MR032LNG70-7###
Drive 4 wheel drive
Transmission 5sp Manual
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Kerb Weight 1840kg
Gross Vehicle Mass 2590kg
Wheelbase 2860mm
Country Of Origin THAILAND



Toyota Hilux Tiger Sport Rider Wagon 4dr SR5 Limited Manual 5sp 4WD 3.0D LN167R-CRMSSTA(05)

New Price (RRP) 980,000
Release Date 1998
Body Style WAGON
Badge SR5 Limited
Doors 4
Seat Capacity 5
Model Code LN167R-CRMSSTA(05)
VIN MR032LNG70-7###
Drive 4 wheel drive
Transmission 5sp Manual
Steering Rack and Pinion
Engine Size 2986cc (3.0)
Cylinders 4
Engine Configuration In-line
Cam Overhead Cam
Valves Per Cylinder 4
Engine Cycle 4 Stroke
Engine Type Piston
Fuel Type Diesel
Fuel Capacity 71L
Fuel Delivery Multi-Point Injected
Method Of Delivery Electronic
Induction Aspirated
Power 88HP
Kerb Weight 1875kg
Gross Vehicle Mass 2590kg
Wheelbase 2860mm
Country Of Origin THAILAND



D4D Toyota Hilux Tiger or Toyota Sport Cruiser

toyota D4D 2002-2004 Hilux Tiger from Thailand's and Dubai's top <a href=Toyota Hilux Tiger dealer and exporter - Sam Motors Thailand" src="images/vehicle-images/D4D-Auto-02.jpg" width="460" height="345" />As mentioend earlier, Toyota released Toyota Hilux Tiger in D4D in late 2001 but only in 2KD engine. The first 1KD Toyota Hilux Tiger was released in 2002. The D4D Tiger is officially called Toyota SportCruiser or Toyota Sport Cruiser. So if you are interested in 2002 Toyota Sport Cruiser or 2003 Sport Cruiser or 2004 Sport Cruiser, please contact us today at thai4x4@gmail.com.

The Double Cabin available in the 2002 is in the 2.5 L Diesel D4D Commonrail TURBO Diesel 2 KD Engine available in the Manual Transmission in 4x4 , 4 doors and the 3.0 L Diesel D4D Commonrail Diesel TURBO 1KD Engine is available only in the AUTO 4x4 Transmission, the standard options are same as above but the 2.5 L Diesel 2KD engine is not equipped with the AIRBAG, but the 3.0 L 1KD engine is available in the same specifications as above, the shape of the 2000, 2001 and the 2002 has slightly changed, (Front Lights, Front Grill, and the Tail Lights), body is same and the interior is unchanged as well. In 2003 Toyota introduced common-rail technology.

toyota 2003 sportcruiser hilux tiger get yours now at SoniThe D4D COMMONRAIL Diesel TURBO Engine was the new Technology used in the 2005 Toyota Hilux Vigo as well. For more information on Tiger, see our page on Hilux Tiger.

The quality of our used vehicles is superb in their class. Customers come looking for Sam Quality vehicle in many markets. Our 97 years of integrity, honesty, great price, great customer service and great speed of delivery have created a fan base in 5 continents of the world not only among distributors and dealers but among end-users, corporations, governmental departments, NGOs and a variety of other small, medium size and large corporations. Experience the Sam Difference today by emailing us at thai4x4@gmail.com today!








Toyota Hilux Tiger

DIMENSIONS & WEIGHT





STANDARD FEATURES

Radio AM/FM

Digital Clock

Alloy Wheels

Green Laminated W/shield

Vinyl Seat

Overall length

mm.

4730

Overall width

mm.

1690

Overall height

mm.

1795

Wheelbase

mm.

2860

Tread Front/Rear

mm.

1485 / 1470

Ground clearance

mm.

225

Seating Capacity



2

CHASSIS





SAFETY FEATURES

Fr. Seat Belts

Child Protection Lock

Retractable Bumpers

GOA Body Structure

Suspension

Front

MacPherson strut type suspension

Rear

Double wishbone suspension

Brakes

Front/Rear

Discs/Drums

Min. turning radius (tyres)

m.

6.6

Fuel tank capacity

litres

71

Tyres



255/70R15

Drive System



4-wheel

ENGINE





POWER FEATURES

Power Steering

Power Window Front

Power Door Lock

Air Cooler

Type



5l-E, OHC

Piston displacement

cc.

2986

Max. Output

Kw/rpm

71/4000

Fuel System



Electronic Fuel Injection

Max. Torque.

Nm/rpm

200/2600

An old press release on the short-lived Toyota Tiger 1Kz-TE Engine

After hanging on to the aging 5L engine for sometime, market pressure has forced Toyota to come up with a superior engine for its sports utility line-up.

With customers demanding for better performance than the normally-aspirated 5L engine can offer, Toyota has decided to install a new engine to the Hilux Tiger SR5 4x4 pick-up as well as the Sport Rider sport utility vehicle. The new engine, the turbo-charged 1KZ-TE, as well as the 5L-E (basically the 5L engine with electronic fuel management) engine both pass the strict Euro II emission standard. But most importantly, the 1KZ-TE motor offers significantly increased output with 125 ps (SAE Gross) at 3,600rpm and a massive 315Nm (EEC net) of torque at 2,000rpm.

There has been confusion over the horsepower output of the new engine, which is measured in SAE Gross instead of the regular EEC net due to marketing reasons. Otherwise, the maximum power of the 1KZ-TE engine would be about 116 horsepower. Nevertheless, it is a brilliant powerplant capable of giving the SR5 tremendous performance uncommon in the pick-up truck segment. Note that this engine also powers other vehicles in the Toyota line-up including the Land Cruiser Prado and the Granvia van.

Acceleration has been improved dramatically over the 5L engine and the Tiger SR5 is the quickest pick-up in the market with a best speed of almost 160km/h. Thanks to the huge amount of torque, it takes no time to accelerate from cruising speed to the truck's best speed. The gearbox doesn't require much force at all if you shift with the right timing. But during full acceleration, it tends to get stubborn and the extra time needed to shift results in lower acceleration figures.

The four-wheel-drive system is easy to use, and the ADD (automatic disconnecting differential) function with shift on the fly allows the driver to switch between two and four-wheel-drive without having to sbest the vehicle. The front torsion bar and rear leaf spring suspension of the Tiger SR5 is average in terms of comfort. It has been tuned for off-road driving and in this department it is one of the best. With the high torque, the Tiger SR5 climbs up gradients comfortably. Toyota claims that it could climb at 46.5 degrees and has approach/departure angles of 36 and 25 degree respectively.

Brakes are vented discs in front and drums at the rear. There are also a Super LSPV (load sensing proportioning valve) and LTS (leading trailing system) systems to improve stopping performance. The cabin is comfortable and neatly designed. The speedometer, tachometer, and gauges in the dash have white background while the steering is a four-spoke type.

Among the highlights in the Tiger SR5us equipment list are driver airbag, seat belts with pretensions and force limits, laminated glass, and a four-sensor ABS system. Other standard features include power windows, power mirrors, central locking, radio-cassette player, fabric seat covers, and 15-inch alloy wheels with large 255/70 tires.

Toyota has managed to make a strong comeback with an outstanding product like the Tiger SR5 1KZ-TE. But of course, sales will be determined by the success of the marketing of the product and it will be interesting to see whether Toyota and it will be interesting to see whether Toyota succeeds in reviving the sales of its pick-up truck line-up.



return to vigo return to index page email us now at thai4x4@gmail.com
Return to our page on Toyota Hilux Vigo Return to Index Page Email us now at thai4x4@gmail.com
